Quality Products. Service Excellence.
Type 4 Mild Steel Freestanding Enclosure
1418 N4 FS
Series
Continuous Hinge Door with Clamps
Application
Designed to house electrical, electronic, hydraulic or pneumatic controls
with provision for panel mounting or rack mounting of equipment.
Provides protection where equipment may be hosed down or otherwise be
very wet, or in specific applications where corrosion is a serious problem.
A variety of inner panels, rack mounting rails and swing out frames are
available to provide flexibility in mounting arrangements.
Standards
UL 508 Type 3R, 4 and 12
CSA Type 3R, 4 and 12
Complies with
NEMA Type 3R, 4, 12 and 3
IEC 60529, IP66
Construction
Formed 12 gauge steel.
Smooth, continuously welded seams without knockouts, cutouts or holes.
Lifting eyes provide for easy enclosure handling.
Doors are supported with heavy gauge continuous hinges.
Doors are secured with heavy duty stainless steel clamps.
Seamless poured-in place gasket.
Provision for light kit mounting.
Mounting channels are welded on the inside of the enclosure for mounting
of optional inner panels or rack equipment rails.
A grounding stud is provided in the enclosure and a bonding stud is
provided on the door.
Finish
Cover and enclosure are finished in recoatable smooth ANSI 61 gray
powder coating.
Optional inner panels are available in white powder coating, or unpainted
galvanized steel.
Accessories
